A Guide to System Hardening:

The topic will address suggested system settings for complying with the PCI DSS v2.0 for a Microsoft Windows Server 2008 with a Domain Controller role. Take note that the following guideline is only a start for hardening the in-scope server.

Ultimately, all services, ports, protocols, daemons, etc that are not specifically required for the functioning of the server should be disabled.

The following PCI DSS requirements are mapped:

Requirement 2: Do not use vendor-supplied Defaults for System Passwords and other Security Parameters.

2.1 Change Vendor-supplied defaults.

2.1.0 Change non-wireless Vendor defaults

Accounts: Guest account status: Disabled
Built-in Guest account renamed
Built-in Administrator account renamed

2.2 Develop configuration standards for all system components.

2.2.2 Disable unnecessary services and protocols

Telnet service: Disabled
FTP Publising service: Disabled
other unnecessary services (8 specific items)*

2.2.3 System Security configuration

Configure IPSec exemptions for various types of network traffic
Digitally encrypt secure channel Data: Enabled
Disable Remote Desktop sharing: Enabled
Do Not Allow Clipboard redirection: Enabled
other system security configuration (66 specific items)*

2.2.4 Remove all unnecessary functionality

Allow Floppy copy and access to all drives and folders in the recovery console: Disabled
Allow Auto Administrative Logon: Disabled
Everyone permissions applied to anonymous users: Disabled
Disable machine account password changes: Disabled
other unnecessary functionality (88 specific items)*

2.3 Encrypt non-console administrative access.

Digitally sign sever communications: Enabled
MS Client to Digitally sign communications: Enabled
Digitally sign secure channel data: Enabled
Encrypting or signing of secure channel traffic

Requirement 3: Protect Stored Cardholder Data

3.5 Protect encryption keys.

3.5.2 Storage

Force strong key protection: User must enter a password each time they use a key.

Requirement 4: Encrypt transmission of Cardholder data across open, public networks.

4.1 Use strong cryptography and security protocols

4.1.0 Using strong cryptography and security protocols over non-wireless

LAN manager authentication level: NTLMv2, refuse LM and NTLM
LDAP signing requirements (Domain Controller)
LDAP client signing: Negotiate Signing
other settings (8 specific items)*

Requirement 6: Develop and maintain secure systems and applications.

6.1 Up-to-date security patches

Configure Automatic Updates: Enabled: 3 – Auto Download and Notify for install
Do not display ‘Install Updates and Shut Down’ option in shut down windows dialog box: Disabled
Reschedule Automatic updates scheduled installations: Enabled
Service Pack for Windows Server 2008 is greater than or equal to 2 (RTM/R2 with latest security patches)

Requirement 7: Restrict access to Cardholder data by business need to know.

7.1 Access restrictions

7.1.1 Enforce Least Privilege

Allow Anonymous SID/Name Translation: Disabled
Check for use of NTFS partition
Do not allow anonymous enumeration of SAM accounts: Enabled
other settings (33 specific items)*

7.1.2 Role-based privilege Assignment

Allowed to Format and eject removable media: Administrators
Deny access to this computer from the Network: Guests
Deny Log on Locally: Guests
Logon Locally: Administrators
other settings (34 specific items)*

7.2 Access Control System

7.2.3 Default ‘deny-all’ setting

Act as Part of the Operating System: No One
Log on as a Batch Job: No One
Debug Programs: No One
other settings (10 specific items)*

Requirement 8: Assign a Unique ID to each person with computer access.

8.2 Authentication Method

Always Use classic Logon: Enabled
CAC Logon required
Do not require CTRL+ALT+DEL: Disabled
other settings (7 specific items)*

8.4 Passwords rendered Unreadable for Transmission and Storage

Do not store Credentials or .NET passports: Enabled
Do not store Lan Manager Password Hash: Enabled
Password reversible encryption: Disabled
Send Unencrypted password to connect to SMB: Disabled

8.5 Credential Management

8.5.9 Password Aging

Maximum password Age is greater than 0 and less than or equal to 90

8.5.10 Password Length

Minimum password length is greater than or equal to 7

8.5.11 Password Complexity

Password complexity: Enabled

8.5.12 Password History

Password History memory is greater than or equal to 4

8.5.13 Account Lockout threshold

Account Lockout Threshold is less than or equal to 6

8.5.14 Account Lockout duration

Account Lockout Duration is greater or equal to 30 or equal to 0

8.5.15 Idle Session Timeout threshold

Disconnect Idle session is less than or equal to 15 minutes

Requirement 10: Track and monitor all access to network resources and Cardholder data.

10.2 Audit Trail automation

10.2.0 Enable Audit

Logoff: Success
Logon: Success and Failure
other settings (4 specific items)*

10.2.1 Individual Access

Logoff: Success
Logon: Success and Failure
Special Logon: Success

10.2.2 Privileged User Action

Audit policy change: Success and Failure
Authentication policy change: Success
other settings (12 specific items)*

10.2.4 Invalid Access Attempts

Logon: Success and Failure

10.2.5 Identification and Authentication Mechanisms

Credential validation: Success and Failure
Authentication policy change: Success

10.2.6 Audit Log Initialization

Application Log Size: Greater than or Equal to 32 MB
Security Event Log Size: Greater than or Equal to 80 MB
other settings (5 specific items)*

10.2.7 Object Creation and Deletion

Directory Service Access: Success and Failure
Directory Service Changes: Success and Failure
other settings (9 specific items)*

10.4 Time Synchronization

10.4.1 Correct System Time

Configure Windows NTP client

10.4.2 Protection of Time Data

Change the Time Zone
Change the System Time (Domain Controllers): Administrators, LOCAL SERVICE (Server Operators: Optional)

10.5 Secure Audit Trails

10.5.2 Audit Trail modification protection

Verify permissions on Application.evtx
other settings (3 specific items)*

10.7 Audit Trail Retention

Application Log size: Greater than or Equal to 32 MB
Security Event Log Size: Greater than or Equal to 80 MB
other settings (5 specific items)*

Requirement 12: Maintain a policy that addresses Information Security for all personnel.

12.3 Develop Technology usage policies

12.3.8 Automatic Session Disconnect

Disconnect Idle Session is less than or equal to 15 minutes
Terminal Services – Set time limit for Disconnected sessions
Terminal Services – Set time limit for Idle sessions

Here is a good reference for PCI DSS recommended hardening guide:

*Halock Security Labs has experts on hand that can help your organization develop a strategy to deploy a ‘Microsoft Windows Server 2008 Domain Controller‘ in a secure, compliant, and cost-effective manner. Please feel free to reach out to us today with any questions that you may have.

Oscar Bravo Jr.
CISSP, CISA, CCDP, CCNP, CCSE, CCSE, MCSE, MCITP, RSASE
